DS-2AE4225TI-D E 2MP Outdoor PTZ Camera — 25× Optical Zoom, IR Night Vision

High-performance DS-2AE4225TI-D E 2MP PTZ camera with 25× optical zoom, robust pan/tilt control, strong IR night vision up to 100 m, and weather-proof build — perfect for large-area monitoring.
The DS-2AE4225TI-D E is a professional-grade 2 MP PTZ CCTV camera designed to deliver reliable, high-quality surveillance for outdoor environments. Featuring a 1/2.8″ progressive scan CMOS sensor and full 1080p resolution, this camera captures crisp video that helps you clearly observe movement, faces, and critical details in both day and night settings.
What sets this PTZ camera apart is its powerful 25× optical zoom — letting you zoom in on distant subjects while maintaining clarity — and the 360° endless pan and -15° to 90° tilt range for flexible coverage across wide areas without blind spots.
At night or in low light, its Smart IR illuminator pushes visibility up to 100 meters, so you don’t lose sight when the sun goes down. The camera also uses 120 dB true Wide Dynamic Range (WDR) to balance bright and dark scenes — ideal for entrances, parking lots, campuses, and facilities where lighting can vary.
Built for all-weather use, the rugged housing resists rain and dust for outdoor deployment, and ease of integration with various DVR systems makes installation flexible. Whether you’re securing a large estate, business perimeter, or public space, this PTZ camera offers versatility and clarity you can rely on.
| Image Sensor | 1/2.8" Progressive Scan CMOS |
|---|---|
| Min. Illumination | Color: 0.005 Lux @(F1.6, AGC ON), B/W: 0.001 Lux @(F1.6, AGC ON), 0 lux with IR |
| Shutter Speed | PAL: 1/1 s to 1/10,000 s NTSC: 1/1 s to 1/10,000 s |
| Day & Night | IR cut filter |
| Zoom | 25× optical, 16 × digital |
| Focal Length | 4.8 mm to 120 mm, 25 × optical |
| FOV | Horizontal FOV: 57.6° to 2.5° (wide to tele) |
| Focus | Auto, semi-auto, manual |
| Zoom Speed | Approx. 3.2 s (optical, wide to tele) |
| Supplement Light Type | IR |
| Supplement Light Range | Up to 100 m |
| Movement Range (Pan) | 360° endless |
| Movement Range (Tilt) | -15° to 90° (auto flip) |
| Pan Speed | Pan manual speed: 0.1° to 80°/s Pan preset speed: 80°/s |
| Tilt Speed | Tilt manual speed: 0.1° to 80°/s Tilt preset speed: 80°/s |
| Proportional Pan | Rotation speed can be adjusted automatically according to zoom multiples |
| Presets | 256 |
| Patrol Scan | 10 patrols, up to 32 presets for each patrol |
| PTZ Status Display | Yes |
| Frame Rate | 50 Hz: 25 fps @(1920 × 1080) 60 Hz: 30 fps @(1920 × 1080) |
| Protocols | UTC protocol (or HIKVISION-C protocol in previous DVR) |
| Image Settings | AGC, white balance |
| Wide Dynamic Range (WDR) | ≥ 120 dB |
| Image Stabilization | EIS |
| Image Enhancement | BLC, HLC, 3D DNR |
| Video Output | Switchable TVI/AHD/CVI/CVBS video output, (NTSC or PAL composite, BNC) |
| RS-485 | Half-duplex mode Self-adaptive HIKVISION, Pelco-P, Pelco-D protocol |
| Power | 12 VDC, max. 20 W (IR: 7 W) |
| Dimension | Ø 164.5 × 295 mm (Ø 6.47" × 11.61") |
| Protection | IP66 (outdoor dome), TVS 4,000 V lightning protection, surge protection and voltage transient protection |
