DS-2CE56D0T-IRF 2MP HD Outdoor CCTV Camera (2.8 mm Lens)**

DS-2CE56D0T-IRF 2MP HD outdoor bullet CCTV camera with 2.8 mm wide-angle lens

A dependable DS-2CE56D0T-IRF 2MP bullet CCTV camera with a 2.8 mm wide-angle lens, Smart IR night vision up to 25 m, and weather-proof design for reliable outdoor monitoring.

Take your property security to the next level with the DS-2CE56D0T-IRF 2.8 mm HD Bullet CCTV Camera — built to deliver crisp 1080p video and solid performance in various lighting conditions.

• The 2 MP CMOS sensor captures clear and smooth footage during daytime and low-light hours, making it easier to spot important details like faces or license plates.
• A 2.8 mm fixed wide-angle lens offers broad coverage, ideal for front yards, entrances, driveways, and larger outdoor areas.
• With Smart IR night vision up to 25 m, the camera automatically adjusts infrared output for balanced illumination in the dark — helping you see more even when conditions get tough.
• The rugged IP67 weatherproof housing stands up to rain and dust, giving you dependable outdoor use year-round.
• Thanks to 4-in-1 analog video support (TVI/AHD/CVI/CVBS), this camera easily integrates with most DVR systems for straightforward installation and setup.

Whether you’re protecting a home, business, or open space, this camera combines simplicity, durability, and clear high-definition viewing to keep what matters secure.

Image Sensor	2 MP CMOS
Max. Resolution	1920 (H) × 1080 (V)
Shutter Time	PAL: 1/25 s to 1/50,000 s NTSC: 1/30 s to 1/50,000 s
Day & Night	ICR
Angle Adjustment	Pan: 0 to 360°, Tilt: 0 to 75°, Rotation: 0 to 360°
Signal System	PAL/NTSC
Lens Type	2.8 mm, 3.6 mm, 6 mm fixed lens
Focal Length & FOV	2.8 mm, horizontal FOV: 101°, vertical FOV: 60°, diagonal FOV: 122° 3.6 mm, horizontal FOV: 79.6°, vertical FOV: 43.5°, diagonal FOV: 93.7° 6 mm, horizontal FOV: 51.9°, vertical FOV: 30°, diagonal FOV: 58.8°
Image Parameters Switch	STD/HIGH-SAT
Image Settings	Brightness, Sharpness, Smart IR
Frame Rate	TVI: 1080P@30fps, 1080P@25fps CVI: 1080P@30fps, 1080P@25fps AHD: 1080P@30fps, 1080P@25fps CVBS: PAL/NTSC
Day/Night Mode	Auto/Color/BW (Black and White)
Wide Dynamic Range (WDR)	Digital WDR
White Balance	Auto/Manual
AGC	Yes
Video Output	Switchable TVI/AHD/CVI/CVBS
Material	Main Body: Metal Enclosure: Plastic
Dimension	Φ 89.9 mm × 70.1 mm (Φ 3.54" × 2.76")
Operating Condition	-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
Communication	HIKVISION-C
Power Supply	12 VDC ± 25%
Consumption	Max. 3 W
IR Range	Up to 25 m
Protection	IP67
